Strip Curtain Door Kit - Complete Ready to Hang
COMMERCIAL, INDUSTRIAL QUALITY
Strip Curtain Doors are the Ideal Solution for Preventing dust, cold air and noise from moving between separated areas. Our Strip Curtain Kit is made from the Highest Quality PVC/Vinyl Strip Material right here in the USA. We recommend you order your Strip Door Kit a little longer than you need and trim the strips to the perfect length.
YOUR STRIP DOOR KIT INCLUDES:
- High Quality Industrial Strength Kit
- Universal Hanger Works in every Situation
- Pre-Punched Ready to Hang PVC Strips
- Easy Installation Mounting Screws Included
- USDA, NSF Approved PVC Strips
- Proudly Made in the USA
Mount Your Industrial Strength, Universal Hanger, Install & Replace PVC strips easily. can be used in a variety of applications and traffic situations.
Jamb Mount
Jamb (Lintel) mounts are installed directly overhead in the doorway. Measure doorway, trim hanger for exact fit.
Wall Mount
Mounts above the doorway, flat to the wall. Measure doorway, add 12" for the strips to cover the wall 6" each side of doorway.
Threaded Rod
Order your Strip Door Kit at your desired width. Universal Hanger can be used suspended by a threaded rod.
The first step to selecting the proper strip width & overlap is to determine your doorway size in conjunction with the type and volume of traffic.
STRIP WIDTHS & OVERLAPS
We made it easy for you.
Choosing the perfect Strip Width & Overlap configuration for your use cases is not that hard. We made it easy for you with our handy guide so you can lock in on your purchase, confidently.
8" Strips & 50% Overlap
Industry Standard Most Common
Most versatile PVC strip door that will withstand pedestrian traffic and also accommodate the person walking with the hand truck. An effective plastic strip barrier, right in the middle in terms of effectiveness and ease of access.
6" Strips & 67% Overlap
Smaller Doorways, Most Economical
Using less overlap with a more economical material is suitable for smaller doorways and pedestrian only traffic. Consider heavier strip for bigger openings or motorized traffic. Light duty solution for walk-in coolers.
8" Strips & 100% Overlap
Industry Standard Full Overlap
Two layers of strips across the doorway, for when larger strips are too heavy. Used mostly to save energy and control negative and positive air pressure, wind, seal off air, noise, dust between the office and warehouse openings.
6" STRIPS & 100% OVERLAP
Walk-In Freezer Industry Standard
Smallest strip in full overlap, two layers of strip across the hanger, provides the perfect seal for walk-in freezer applications. Also used for smaller openings as an economical barrier for air pressure, temperature, noise, dust.
12" STRIPS & 67% OVERLAP
Heavy Duty, Big Openings, Machine Traffic
Big heavy strip for large openings, forklift traffic, trucks and machinery. Uses less material and easier to pass through than full overlap. If lighter loads are typically carried, too heavy of strip may drag product off of the forklift.
8" STRIPS & 25% OVERLAP
Economical Commercial Industrial
Industry standard strip width, using less overlap requires less strip material and makes perfect for high traffic pedestrian traffic. Carry loaded serving trays or boxes through with ease, Good for walk-in coolers.
12" STRIPS & 100% OVERLAP
Air Pressure & Energy Savings
Full overlap with largest and heaviest strip, curtains extra large doorways, heavy machinery, forklifts, loading docks or exterior doorways with excess wind. Openings with high levels of negative and positive air pressure.
Every available Industrial Strength PVC Strip Material option for your application, meeting Federal and International standards for Incidental Food Contact.
Cut Sheet | Technical Specifications | Certificate of Compliance
The Industry Standard
Crystal clear separation, flexible smooth PVC strip for a variety of custom applications, indoor or outdoor from -10° to 150° F. Versatile and economical for a wide range of applications.
Heavy-Duty Industrial Traffic
Tough PVC material reduces scratching from loads, preventing wear of the PVC strip and increasing PVC strip lifespan. Perfect for Forklift & Machine traffic in environments from -10° to 150°.
Walk-In Freezer PVC Strips
Crystal clear and specialized low temp PVC formulation, ideal for restaurants, food service and food storage applications where there is a pedestrian traffic and temperatures down to -40°F.
Bug Repelling PVC
Our exclusive Anti-Insect formulation repels flying insects with Citronella and prevents infiltration of the facility. Yellow color inhibits insect’s ability to detect light behind curtain.
PVC for Dust & Static
Specially formulated PVC strip material for static-sensitive or high-dust applications. For data centers, clean rooms, manufacturing facilities, and areas with flammable materials.
PVC Privacy Curtain
Flexible, opaque black plastic strip material totally restricts the view between areas while maintaining workflow. Perfect for conveyor belt openings to prevent visual access.
Welding Safety PVC
Safely section off space and protect workers from welding hazards by blocking UV rays and providing a barrier against sparks, operating temperatures between 0° to 150° F.
